13.73:1 Geared Nema 11 Stepper Motor with Integrated Planetary Gearbox 1.8° 2 Phase High Torque 11Ncm(15.58oz·in) Bipolar 1.0A 7Ω 88mm 4-Lead Shaft 18mm φ6mm Cable 1M 3D Printer DIY CNC
4.8 (118 items)
Limited Time SaleUntil the end
00
31
21
US$54.00 cheaper than the new price!!
Free shipping for purchases over $99 ( Details )
Free cash-on-delivery fees for purchases over $99
Free cash-on-delivery fees for purchases over $99
See all stores
Please note that the sales price and tax displayed may differ between online and in-store. Also, the product may be out of stock in-store.
Used US$36.00
Product details
| Management number | 211760429 | Release Date | 2026/04/04 | List Price | US$36.00 | Model Number | 211760429 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Size Specifications: 13.73:1 Geared Nema 11 Stepper Motor with Integrated Planetary Gearbox dimensional parameters are as follows. Body size 28x28x88mm (1.11x1.11x3.47in), Shaft length 18mm, Shaft diameter Ø6mm, D-cut length 13mm, Lead color Black (A+) Green (A-) Red (B+) Blue (B-), incl. Cable 1M, Weight 325g.
- Performance Data: Ratio 13.73:1 Planetary Gearbox Nema 11 Stepper Motor, Step angle 1.8 Degree(200 steps/rev), 2 Phase Holding torque 11Ncm (15.58oz·in), Resistance 7.0Ω, Rated current 1.0A, Inductance 7.0mH±20%, Rotor inertia approx 29g.cm².
- Safety Specifications: This Nema 11 Stepper Motor with planetary gear ensures safe and reliable performance, and here are its key safety parameters. Dielectric strength 500V A.C 1 MINUTE; Insulation class(UL) B (130℃) [266°F]; Insulation resistance 100MΩ MIN; Temperature rise 80K MAX; Operation ambient temperature -20℃～+50℃ [-4°F～122°F]; Operation ambient humidity 15%RH～95%RH.
- More Power, Less Noise: Built with advanced steel cores and precisely tuned windings, this nema 11 planetary reducer stepper motor generates up to 20% stronger holding torque while significantly reducing noise output. Achieve smoother machine motion and lower acoustic impact.
- Important Insights: Faster speeds reduce torque, with operation recommended at 0–600 RPM. Lower current reduces torque and temperature rise, and lower voltage also reduces torque (ideal voltage range: 12–24V DC). The 28mm Stepper Motor with Planetary Gearbox fits 3D printers, DIY robots, CNC machines, and other automated systems, offering a small size and high torque for performance-driven tasks.
| Brand Name | YEJMKJ |
|---|---|
| Manufacturer | YEJMKJ |
| Included Components | motor |
