3806-2RS 3806 RS Bearing 3806 2RS Double Row Sealed Angular Contact Ball Bearings 30 * 42 * 10 mm

BearingGeneralDouble row angular contact ball bearings provide the function of a pair of single row angular contact ball bearings, arranged back-to-back, but requiring less space.Double row angular contact bearings provide very stiff, rigid bearing arrangements. They are also able to accommodate combined loads and are very suitable in supporting tilting moments.MisalignmentDouble row angular contact ball bearings must not be exposed to any misalignment.Minimum LoadBearings require a minimum load under all operating conditions to ensure kinematically correct rolling element function.For double row angular contact ball bearings the minimum load must be 1% of the dynamic load rating.Pruduct ApplicationsUltra Precision Surface Grinding Spindle, Precision Surface Grinding Spindle, Heavy-Duty Precision Boring Spindle, Six-Spindle Automatic Screw Machine, Ultra Precision Grinding Work-head, Precision Tool-room Surface Grinder Spindle, etc.Widely used in household appliances, garden machinery, outdoor vehicles, industrial production, etc. Suitable for skateboards, longboards, inline skates, scooters, robots, ship rudder axles, etc.Features: small friction, fast speed, smooth, low noise.

• Bearing
• Item Number: 3806-2RS; Model Number: 3806-2RS
• Torque Capacity: 30*42*10mm; Inner (d): 30 mm; Outer (D): 42 mm; Width (B): 10 mm
• Structure: Double Row Angular
• Surface Roughness: Ra 0.05
