Handheld DC Milliohm Meter with TFT-LCD Display Measurement Range 10μΩ～200KΩ DC Resistance Milliohm Meter
4.3 (103 items)
Limited Time SaleUS$384.00 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211160937 | Release Date | 2026/04/04 | List Price | US$256.00 | Model Number | 211160937 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Shipping Policy : Battery and Liquid not included during the shipping Application * All kinds of low, medium, high resistor * Switch contact resistance * Enamel-insulated wire resistance * Connector Contact * Relay/switch connector contacts * Transformer, Inducer, Motor, Deflection coil winding resistance * Welding Spot * Wire resistance * Metal riveting resistance of vehicle, vessels, airplane * Pure resistance * The resistance of motor and transformer * Printed board line and hole resistance * Low resistance character of Electromechanical Components Technical Specifications * Model: AT518L * Parameter: DC Resistance * Accuracy: 0.1% * Measurement Range: 10μΩ～200KΩ * Measurement current: I-Max: <1A Current Mode: High Current * Range: Auto, manual, nominal with 7 ranges * Speed: 3 t/s * Display: ABS, PER, SEQ compare way * Display Max: 20000dgt * Adjustment: Short-circuit Zero-Adjust for each range * Comparator: Build-in sorting record, GD/NG sorting result display * Trigger: Internal, Manual * Interface: Four-terminal * Method: Build-in Mini-USB Interface（VCP） * Other features: TFT-LCD display; Keypad lock; Data hold; Adjustable background light; Auto power off; Switch in both Chinese and English; * Size and weight: Outside（mm）: 130.23 (Width)x210.76(Height)x37.88 (Depth) 650g * Power requirements: Input: 100-240V~50/60Hz 0.35A Output: 9V 1A DC * Accessories: ATL501B: Four-terminal Kelvin Test Clip ATL909: DC resistance adaptor ATL202: Carrying Case * Optional Accessories: ATL105: Mini-USB communicable cable ATL501C: Four-terminal test Probe ATS518 data acquisition software
- ★ Gorgeous dual-colure cast shell
- ★ Automatic power off Function,Keypad lock function
- ★ 3.5 inches, Truecolor 16M, TFT-LCD Display
- ★ Four-terminal resistance measurement.
- ★ Mini-USB interface, SCPI compatible command sets
| UPC | 681013842766 |
|---|---|
| Brand Name | VTSYIQI |
| Item Weight | 650 Grams |
| Manufacturer | VTSYIQI |
| Power Source | Battery Powered |
| Item Dimensions | 11.81 x 1.97 x 7.87 inches |
