High Voltage Insulation Tester 5kV Insulation Resistance Tester with Insulation Resistance Range 0.50MΩ～2.00TΩ Rated Voltag 250v~5Kv Short Circuit Current 5mA MAX

Main functions Suitable for insulation resistance testing of cables, motors, generators, transformers, mutual inductors, high-voltage switches, lightning arresters and other equipment Insulation resistance range: 0.50MΩ~2.00TΩ Rated voltage: 250v~5kV (5 gears) Short circuit current: 5mA MAX Voltage monitor function, test timer function, discharge function Insulation resistance test (IR); polarization index test (PI); absorption ratio test (DAR); ramp test (RAMP); filter test (FR); voltage test (V); current test (nA) Product Features Touch color screen combined with buttons and band knob, the function is straightforward to complete the test with one key, and the query record is easy to operate. Rich display content, the same screen display: various test modes and insulation resistance value, output voltage and voltage of the measured object, current, test timing, test time, battery power, operation help, etc. Double-layer shell structure, rugged and durable, protection grade IP65. Large capacity rechargeable lithium battery. Voltage monitor function, automatic monitoring of the measured object charged voltage. Test timer function, automatically record the test time. Automatic discharge function, automatically release the charged charge of the test object after the test. Storage function, can automatically store a total of 1000 sets of real-time test data with test date and time, test timing. Upload function, the recorded data can be uploaded to computer through USB communication line for statistical analysis. Other parameters Functions: insulation resistance test (IR); polarization index test (PI); absorption ratio test (DAR); filter function (4 time options 10S, 20S, 30S, 40S). Voltage test (V); Current test (nA). Power: Rechargeable lithium battery 5.2Ah Rated voltage: 250V, 500V, 1kV, 2.5kV, 5kV Output voltage accuracy: (5%rdg～10%rdg)±10V Insulation resistance

• Insulation resistance range: 0.50MΩ～2.00TΩ
• Rated voltage: 250v~5Kv (5 gears)
• Output short-circuit current: ≥5mA
• Voltage monitor function, test timer function, discharge function
• Suitable for insulation resistance testing of cables, motors, generators, transformers, transformers, high-voltage switches, surge arresters and other equipment
