LCR Meter LCR Bridge Handheld LCR Meter with Measurement Frequency 100Hz, 120Hz, 1kHz，10kHz Test Functions L,C,R,Z Accuracy 0.2% USB-HID Communication Internal Trigger Mode

Specifications●Test Functions: L,C,R,Z ●Accuracy: 0.2% ●Measurement Frequency: 100Hz, 120Hz, 1kHz，10kHz ●Measurement Speed: 4 times/s, 1.5 times/s●Display Range:L: 0.01uH-9999H C: 0.01pF - 9999uFR,Z: 0.0001Ω - 99.99MΩD:0.0001–9.999Q:0.0001~999.9 ●Source Resistance: 100Ω●Display Reader: 49999●Signal Level: 0.6Vrms, ±10% accuracy●Trigger Mode: Internal●Comparator: 1 sets, compare main parameters ●Comparator Mode: SEQ/ABS/PER●Adjustment: open/short clear zero ●Files: USB storage●Interface: USB-HID●Protocol: SCPI●Other Functions: Touch screen; USB-HID communication, compatible SCPI ; English & Chinese language, adjustable back light, auto power off(APO)●Power Supply: input: 100-240V，50Hz, 0.35A, output:9V 1A DC●Dimension & Weight: 90*195*35.5mm 400g

• Handheld Digital LCR Meter with high performance 32-bit ARM microprocessor.
• TFT true color LCD display. Keypad and touch screen double control.
• Adopt Li- battery supply power, USB communication.
• The highest frequency of 10kHz. constant 100Ω source internal resistance, 0.6Vrms measurement voltage level, and 0.2% accuracy.
• ◆High brightness, true color LCD display ◆touch screen ◆Chinese and English switching ◆USB-HID communication ◆Correction function: full range open circuit and short circuit sweep frequency clearing. ◆1300mAh rechargeable lithium battery◆Long working hours: 14 Hours @30% Brightness
